Suitable for various materials such as steel, stainless steel, aluminum, glass, polystyrene, polyethylene, etc.
Built-in standard block of 4.00mm for fast calibration
LCD display with backlight
With RS232 interface
|
Technical specification |
|
Measuring range |
0.75-300mm/0.03-12" |
|
Resolution |
0.01mm/0.001" for range<100mm/4" |
|
0.1mm/0.01" for range≥100mm/4" |
|
Velocity |
1000～9999m/s (3281-32806ft/s) |
|
Power supply |
2×1.5V AAA batteries |
|
Dimension |
74x150x32mm |
|
Weight |
250g/8.3oz |
|
Specification of transducers
|
Code |
Frequency |
Measuring Range |
Diameter |
Temperature |
Minimum size of steel
pipe for measurement
(diameter x wall thickness) |
Application |
|
ISU-T01 |
2.0MHz |
3.0-300mm/0.12-12.00" |
φ16.3mm/0.64" |
<60℃/140°F |
30x3mm/1.20x0.12" |
for casting steel |
|
ISU-T02 |
7.5MHz |
0.75-50mm/0.03-2.00" |
φ8.5mm/0.34" |
<60℃/140°F |
15x2mm0.60x0.08" |
for thin material |
|
ISU-T03 |
5.0MHz |
1.2-230mm/0.05-9.05" |
φ10.8mm/0.43" |
<60℃/140°F |
20x3mm/0.80x0.12" |
general use |
|
IEU-T04 |
5.0MHz |
3.0-100mm/0.08-4.00" |
φ13mm/0.51" |
<300℃/572°F |
30x3mm/1.20x0.12" |
for high
temperature |
