With Low-high indication and alarm
Average calculation of max. 9 readings
Memory of max. 5000 readings with location number
With USB interface
Built-in standard block of 4.00mm for fast calibration
LCD display with backlight
|
Technical specification |
|
Measuring range |
0.7-400mm/0.03-16' |
|
Resolution |
0.01mm/0.001' for range < 100mm/4' |
|
0.1mm/0.01' for range≥100mm/4' |
|
Velocity |
1000-9999m/s (3281-32806ft/s) |
|
Power supply |
2×1.5V AAA batteries |
|
Dimension |
64×116×27mm |
|
Weight |
220g/7.8oz |
|
Specification for transducers
|
Code |
Frequency |
Measuring Range |
Diameter |
Temperature |
Minimum size of steel pipe for measurement (diameter x wall thickness) |
Application |
|
ISU-T12 |
2.0MHz |
2.0-400mm/0.08-16.00' |
Φ16.3mm/0.64' |
<60℃/140℉ |
30×3mm/1.18×0.12' |
for casting steel |
|
ISU-T06 |
7.5MHz |
0.7-50mm/0.03-2.00' |
Φ8.5mm/0.34' |
<60℃/140℉ |
10×1mm/0.40×0.04' |
for thin material |
|
ISU-T08 |
5.0MHz |
0.8-300mm/0.03-12.00' |
Φ10.8mm/0.43' |
<60℃/140℉ |
10×1.2mm/0.40×0.05' |
general use |
|
ISU-T13 |
5.0MHz |
3.0-100mm/0.08-4.00' |
Φ13mm/0.51' |
<350℃/662℉ |
20×2mm/0.80×0.08' |
for high temperature |
